SANY SMHR200 - RAIL GANTRY
Built for heavy-duty tasks, the SMHR200 excels where reach, power, and precision matter most. It’s ideal for ports, recycling yards, and industrial sites that need machines to perform continuously under harsh conditions. With dual power options, smart safety systems, energy-efficient technology, and other features, the SMHR200 delivers strength and reliability while keeping operations smooth and efficient.
Specifications
Machine Specifications
| Performance / Capabilities | |
|---|---|
| Capacity | Over 11.3 t at 32.5 m reach |
| Cycle time | 90° turn in 45 seconds |
| Efficiency | Average 700 t/h |
| Temperature range | -45°C to +45°C with auto fire extinguishing |
| Energy saving | Up to 15% reduction via energy recovery |
| Fuel usage | 60–80 L/h typical |
| Engine | |
|---|---|
| Model | 2 × Deutz D13S3T9 |
| Rated power | 2 × 353 kW / 2,000 rpm |
| Torque | 2 × 2,350 Nm / 1,100–1,500 rpm |
| Emissions | COM III / CN IV |
| Fuel tank | 4,000 L |
| Power system | Dual — diesel + electric motor option |
| Hydraulic System | |
|---|---|
| Type | Electronically controlled positive flow |
| Main pumps | Kawasaki (engine and e-motor connection) |
| Max system pressure | 34.3 MPa |
| Hydraulic oil tank | 1,500 L |
| Slewing / Swing | |
|---|---|
| Slewing gear | SANY |
| Max rotating speed | 5 rpm |
| Turning cycle | 45 seconds for 90° rotation |
| Safety | Dynamic anti-tipping and bracket protection |
| Cabin | |
|---|---|
| Lift height | 2,300 mm |
| Temperature operation | -45°C to +45°C |
| Safety | Automatic circular fire extinguishing system |
| Visibility | Excellent horizontal and vertical |
| Dimensions & Weight | |
|---|---|
| Working gauge | 10,500 mm |
| Wheelbase | 10,500 mm |
| Max travelling speed | 2 km/h |
| Operating Ranges | |
|---|---|
| Max operating radius | 32.5 m |
| Max operating height | 36 m |
| Max operating depth | -10 m |
| Boom options | 16 m / 19.5 m |
| Stick options | 15 m / 16 m |
| Lift Capacities (Grab Not Included) | |
|---|---|
| Load at max reach | Over 11.3 t at 32.5 m |
| Average efficiency | 700 t/h |
